PITCH 10MM INDOOR FULL COLOR LED DISPLAY-SHENZHEN TOPVISION OPTOELECTRONIC TECHNOLOGY CO., LTD _

PITCH 10MM INDOOR FULL COLOR LED DISPLAY

MOQ ： piece

Lead Time ： Days

Inquiry Start Order

Payment : L/C，T/T，Western Union, Money Gram, Credit Card, Paypal

Spec

· Brightness: 1200CD/㎡

· Model: PH10-SMD-IR

· Cabinet Size: Width: 640mm, Height:640mm, Depth:150mm

· Cabinet Weight: 22Kgs

· Power consumption: Max: 620 w/sqm; Average : 310w/sqm

· Application: Indoor use, AV rental

Features:

1. For indoor rental use withmoderate viewing distances

2. Easy configuration andmaintenance

3. Lightweight and slimcasing

4. Cost effective

5. Can be stacking andhanging

6. Particularly suited foruse at large

Model Number	PH10-SMD-IR
Description	aluminum touring cabinets with hanging function
Application	Indoor use, AV rental
Pixel configuration	1R1G1B SMD 3-in-1 3528 style black face LED
Pixel pitch	10mm
Pixel resolution per standard cabinet	W64 x h 64pixels
Standard cabinet dimension	Width: 640mm, Height:640mm, Depth:150mm
Module size	Width:320mm, Height:160mm
Pixel resolution per module	W 32x h 16pixels
Pixel density per sq/m	10,000 dots per square meter
Minimum viewing distance	Minimum 10 meters
Brightness	1,200CD/M2
Grey scale	4096 steps
Color Number	68.7194billion
Display Mode	Synchronous with video source
Data refresh rate	≥1000HZ
Driver IC	MBI5024
LED drive	1/4 scanning, constant current
Control system type	ZDEC V8
Control software name	LED Manager
Viewing angle	Vertical 120° Horizontal 140°
Temperature range	-10℃ to +50℃
Ambient Humidity	10%-99%
Service access	Rear
Standard cabinet weight	22Kgs(0.64x0.64m)
Power Consumption	Max: 620 w/sqm; Average : 310w/sqm
Protection Level	Front: IP31 Rear: IP31
Lifetime to 50% brightness	75,000hr
LED Failure Rate	<0,00001(Led display line standard <0,0001)
MTBF	> 10.000 hours
Input power cable	AC110V to 220V
Signal input	DVI
Certification	CE, ROHS, FCC marked
Warranty	2 Years quality warranty, 10 YEARS SPARE PARTS SUPPORT
